CT Type
Electronically Controlled Horizontal Uncoiler
Solutions
Features
- Using palletizer coils to minimize material loading time and save man power to increase productivity. It is the best partner of technolgy industry and is pouplar used in terminal industry.
- New innovation rotate spindle universal designed to reduce coil loading plate friction to more smoothly and control box pole can be moved base on loading plate different diameter.
- Easily maintain and make sure die and puncher lifetime to directly increase productivity.
Specifications
CT Type
| Model | CT-1000 | CT-1500 | |
|---|---|---|---|
| Width of Material | mm | 1000 | 1500 |
| Max. Coil O.D. | mm | 1000 | 1000 |
| Rotational Speed | R.P.M | 0~24 | 0~24 |
| Uncoiler Motor | HP | 1/2 | 1 |
| Uncoiler Inverter | kW | 0.75 | 0.75 |
Specialty
- • Automatic advancer to suit varied high speed punching process,high sensitivity material monitoring system to control feeding process synchronous to press.
- • Height efficiency
- • Height stability
Accessories
- Uncoiler motor with inverter control.
